Complete setup with on board fixed +/- 12V power supply, variable 0 to +/-12V power supply, discrete millivolt sources, digital voltmeter, 1KHz source, bread board, loose components including IC 741 and a detailed manual. The following experiments can be carried out:
To use op-amp as inverting, non-inverting, differential amplifier and as an adder.
To study CMRR of an OP-AMP and also use OP-AMP as an Integrator and Differentiator.
To study the performance of the weighted-resistor digital to analog (D/A) converter using an OP-AMP.
To study the performance of the R-2R ladder D/A converter using an OP-AMP.
To construct a logarithmic amplifier using an OP-AMP.
To construct an antilogarithmic (exponential) amplifier using an OP-AMP.
To study the performance of the Schmitt Trigger using OP-AMP.
