Model: DT-MV
Experimental kit to study the working and hence to draw the timing diagrams of an astable and a monostable multivibrator using IC 555 timer. Complete with 5V power supply, pulse generator and a digital voltmeter.
The following studies can be carried out
The following studies can be carried out
1. Operation as a free running multivibrator
2. Operation as a monostable multivibrator
3. Operation as a preset time delay
Complete in all respect with detailed manual and experiment video.
