L-C-R SET
Model: DT-LCR-D
This experimental setup is used to measure the voltage across the inductance (L), Capacitance (C) & Resistance (R) of a Series LCR circuit for different frequencies of the input voltages with the help of an AC millivoltmeter. It is used to study the variation of impedence of L & C with frequency of the impressed voltage and to draw the resonance curve of the series LCR circuit & to determine the Q factor of the circuit. Complete with audio oscillator – sine wave 0-10V p-p 10KHz with digital frequency counter, digital AC voltmeter, digital AC ammeter or voltmeter, digital frequency counter, different values of L, C & R. Complete in all respect with detailed manual and experiment video.
