Eye Pieces: Wide field 10x eye piece with 22mm F.O.V

Observation Head: Binocular / Trinocular head inclined at 30⁰ with inter pupillary distance of 48-75mm.

Nosepiece: Inward, Quintuple revolving nosepiece ball bearing type with proper click stops.

Mechanical Stage: Rackless, double plate stage size 190mm x 160mm. X/Y travel range75mm x 50mm. Double specimen holder clip.

Objectives: High contrast, infinity corrected Plan achromatic objectives 4x (N.A 0.10, W.D 25mm), 10x (N.A 0.25, W.D 6.7mm), 40x (N.A 0.65, W.D 0.6mm) and 100x (oil, N.A, 1.25, W.D 0.17mm), anti fungal, anti reflection coated.

Condenser: Abbe condenser N.A 1.25 with aspheric lens. Iris diaphragm with frosted white filter, anti fungal and anti reflection coated.

Focusing Control: Co-axial coarse and fine focusing on gear systems for smooth operation. Fine adjustment 0.2mm/rotation with maximum 2 micron scale increment.
