Model:DT- BOLTZ
The apparatus consists:
(a) A digital millivoltmeter (0 – 9.99 V) to measure the voltage across the diode.
(b) A highly stabilized power supply whose voltage can be varied in steps of 1 mV using a ten – turn potentiometer.
(c) A digital current ammeter ( 0 – 500 mA).
Diodes: Silicon diodes & Germanium diodes
Complete in all respect with detailed manual and experiment video.
